Specifications:
- Cartridge Weight: 7.5 g
- Cartridge Body: Padauk wood
- Cantilever: sapphire
- Stylus: super fine line contact nude diamond
- Vertical Tracking Angle: 20 degrees
- Coil: pure iron crossed-coil with single crystal high purity copper
- Output Voltage: 0.75 mV at 3.54 cm/sec.
- Internal Impedance: 23 ohms
- Frequency Response: 20 – 20,000 Hz ± 1 dB
- Channel Balance: better than 1 dB
- Channel Separation: better than 30 dB
- Dynamic Compliance: 7 um/mN
- Recommended Loading: 250 – 1,000 ohms
- Recommended Tracking Force: 2.1 g ± 0.1 g
- Tracking Ability at 315 Hz / 2 g: 60 uM
- Recommended Tonearm Mass: medium
- Break-in Period: 50 hours
Instruction Manual
Charisma Audio MC-M Manual
